Assuming you’ve passed your amateur radio “Foundation” exam and have your callsign, your next thought may be – how do I get on air? Here’s some guidance to get you started:
Want a one-page printable guide? See our Getting Started Guides |
Getting started on VHF / UHF
This is where most new radio amateurs start. Using these frequencies, you will be able to talk locally to other amateurs.
Depending on the type and height of your aerial and height, distances of up to 50 miles are possible. Ideally, you would be looking to get a radio and antenna that can use the 2 metre and 70cm frequencies, and will allow you to make contact with other radio amateurs using one of the network of nearby repeaters.
The common options are as follows:
- Handheld: You can get started with a handheld radio for around £25. These come with a short antenna that can be used over a fairly short range (a few miles) at a power of 5 watts (you are allowed 10 watts when you get started). These work best outdoors, and for best results, you would need to connect to a better antenna (eg. Roof, loft, car). Many amateurs own at least one of these, but they do have their limitations. We have a guide dedicated to “your first handheld” which explains the limitations
- At home: If want to transmit from indoors, you may want to consider a “base station” (£80+). These run on 12 volts, so you will also need a mains power supply (£40+). Best results will come from a vertical antenna (£30+, just under a metre long) fixed high up on the roof. It will be connected to your station via co-ax cable. If you can’t get an antenna on the roof, an antenna placed high up in your loft is an option. In some cases, an antenna close to a window, or hung from the window can be used.
- Mobile: “Base stations” can also be installed in cars. Typically, this is either a 5/8 wave antenna attached to a magnetic base, or a roofrack/hatchback clip. The co-ax is normally fed through a rubber door seal
See also: Getting started with repeaters | Sample VHF QSO
An example of a 2 metre contact via the “calling frequency” |
Getting started on HF
HF frequencies will let you talk around the world. Radios for HF are more expensive (£400+, but second-hand ones are available).
You also need a larger antenna. These can be simple long lengths of wire, or more expensive specialist antennas. These ideally are set up in the garden, but loft antennas can be effective too. HF radios require a power supply unit (£40+) and unless your aerial is cut for a specific frequency, you’ll want an antenna tuning unit (£100+) to be able to work multiple bands. Auto-ATUs save a lot of hassle, but usually cost more than manual ones.
We have a series of three guides on getting started with HF, covering radios, bands and antennas. See
- Part 1: The HF Bands – A look at what to expect from each of the HF bands
- Part 2: Selecting a Transceiver – What to consider when buying your first rig
- Part 3: Aerials – A look at feeders, HF aerials, and options for what may work for your shack
Handy tips on buying a radio
- Just because Foundation only allows you 10 watts, if you think you might progress to Intermediate and Full, buy a radio and power supply that will run at higher powers
- Plan to work portable? Think about where you want to work – home, car, portable. Do you want three radios, or just one you can transport around?
- Shop around, and talk to other amateurs before you buy!
Getting started with other modes
- Digital Voice: There are two main systems are ‘DMR’ and ‘D-Star’, which are relatively new and mostly use UHF. Radios are usually handheld, and so need antennas like those mentioned under “VHF/UHF”. Radios connect to local digital repeaters, which are connected to the Internet. This means that from a handheld radio, it’s possible to talk around the world. A basic DMR radio costs £100+. The system is fairly new and are only used by a small percentage of amateurs. Repeaters are only available in some parts of the country.
- Data Modes: By connecting your radio to a computer, you can use data modes such as PSK31 (typed messages), JT-65 (weak signal messages) and SSTV (images). We have a separate guide on these. See: Getting Started with Data Modes
- Morse / CW: Still very popular, and gets through where other modes don’t. There are several ways to learn Morse code, and you’ll need a radio that allows you to connect a Morse key or paddle.
Hopefully this short guide has helped. If you have any questions, or better still, any tips – please add them as a comment below!
Getting on the HF bands is not as expensive as you indicate.
If a newly licenced person can weild a soldering iron there are kits available.
Just made one for my father to encourage him to take the exam.
Just 5 watts CW (A1A) on a single band , I chose 7 Mhz (40m) for about £60 boxed.
The aerial I built is a single band magnetic loop made from coax and also have a quarter wave thats a 10m piece of wire with a 10m counterpoise .
No ATU required once it has been set up .
The same company producing these kits is selling a 50 w amp kit too that can be added.
Foundaton is 10W so the next level exam would be required to use this.
Hope he takes the exam soon :-)
G1BVI
As I understand it, foundation licensees are limited to pre-built retail units and are not permitted to build their own equipment.
also a new entrant into the HF transceiver market is a chinese company call Xeigu
they do a 20w transceiver called a G90 at under £400 new for a 160mtr to 10mtr SDR (software defined radio) with built in ATU, AM,SSB,CW with waterfall display, CW decoder and latest firmware update gives FM on 10mtr
there is an active group on groups.io for support and help
hi i have been using a reciever for a while now and have decided to get a transmitter . im a disabled oap so money is tight . i have seen mobile sets for under £100 but are they any good ? or would i be better with a second hand better model i have an X30 antenna .obviously a base unit would be best but they seem out of my price range . i have a couple of power supplies from my cb days . HELP .. ADVISE PLEASE
I’m guessing you mean VHF/UHF mobile radios and yes they’re OK.
